Description
Product highlights:
1.30 times continuous optical zoom: The drone pod is equipped with a high-performance optical lens that can achieve 30 times continuous seamless optical zoom, providing detailed and close-up views of the target.
2. High precision laser ranging: With its high-precision laser ranging technology, this drone pod provides accurate target positioning, ensuring the accuracy of positioning in various environments.
3. Human vehicle recognition: F2IVR-30 is equipped with additional human vehicle recognition function, further enhancing its ability in vehicle tracking.
4. 360 ° infinite cycle rotation: The three-axis universal joint allows for 360 ° full rotation, achieving complete coverage of the surrounding environment without any blind spots.
5. Small and lightweight: Despite its advanced features, this drone pod is small in size, light in weight, low in power consumption, and highly portable and efficient.
Parameters
| MODEL | F2IVR-30 | |
| System specification | System type | Gyro stability |
| Weight | 1050g | |
| Stable system | Platform type | Tri-axis |
| Azimuth | 360°rotation | |
| pitch | -100°～+100° | |
| Maximum search angular velocity | ≥100°/s | |
| Stability accuracy | 0.1mrad(1°/2HZ) | |
| Angular position accuracy | ≤0.3° | |
| Visible light camera 1 | Resolution and frame rate | SONY7520
1920×1080 @60fps |
| FOV | 63°×35°～2.3°×1.3° | |
| Visible light camera 2 | Resolution and frame rate | 1920×1080 @60fps |
| FOV | 38.4°×22.2°(8mm prime lens) | |
| Infrared camera | Resolution and frame rate | 640×480@60fps |
| SMALL FOV | 12.5°×9.4°（35mm prime lens） | |
| Ranging | Laser Ranging | Range≥3km;
Accuracy±1m |
| Tracking module | Frame rate | 60Hz |
| Tracking speed | ±48 Pixel/frame | |
| System external interface | Control | RS232、NET |
| Video output | NET、SDI | |
| Power supply | Power | 12～28V |
| Power consumption | Av≤15W，Max≤30W | |
| Environmental conditions | Operating temperature | -10℃～+50℃ |
| Storage temperature | -40℃～+60℃ |
Dimensions
How it works:
F2IVR-30 utilizes advanced image processing technology to continuously search and track long-distance personnel/vehicles. The integration of high-resolution photoelectric sensors, uncooled infrared cameras, and laser rangefinders ensures strong target detection and recognition capabilities under day and night conditions. Its compact and lightweight design, coupled with a three axis three frame structure and high-precision electronic image stabilization technology, provides unparalleled imaging experience for industry users.
Frequently asked questions:
Q: Can this drone pod be installed on any type of aircraft?
A: Yes, the F2IVR-30 can be mounted on fixed wing, single rotor, multi rotor, and other aircraft, providing versatility for various applications.
Q: Is laser ranging technology accurate?
A: Of course! The high-precision laser ranging technology used in the drone pod ensures precise target positioning and unparalleled results.
Q: Which industries can benefit from using this drone pod?
A: This drone pod is very suitable for fire rescue, forest fire prevention, power inspection, and any other field that requires advanced target tracking and monitoring capabilities.
