Description
Product highlights:
1. Continuous zoom high-definition visible light camera+35mm lens uncooled infrared camera: 30x three light infrared tracking universal joint and continuous zoom high-definition visible light camera, providing exceptional clarity and detail.
2. Three axis gyroscope stability system: The built-in three axis gyroscope stability system of the universal joint provides significant stability, which can achieve more stable images.
3. Image stabilization, target search, tracking, and positioning: This universal joint is equipped with the latest image stabilization technology to ensure that your lens remains stable and clear. Advanced target search and tracking capabilities further improve performance, allowing you to easily track and locate the desired targets with the highest accuracy.
4. Raw high-definition video storage (optional): For those who require extensive storage capabilities, this universal joint provides storage options for raw high-definition videos.
5. Integrated design, quick disassembly of structure, and convenient installation: The universal joint is designed with an integrated design, making installation convenient.
6.30x continuous optical zoom: With its impressive 30x continuous optical zoom, this universal joint can capture even the smallest details, providing unparalleled versatility and flexibility.
7. High precision laser ranging and target positioning: The universal joint has high-precision laser positioning function, which can achieve precise target positioning.
8. Artificial intelligence human vehicle recognition function: Improve tracking accuracy through human vehicle recognition function.
9.360 ° infinite cycle rotation: can capture clear panoramic views and clear lenses from various angles.
10. Small size, light weight, and low power consumption: The compact and lightweight design of this universal joint makes it highly portable without affecting performance.
Parameters
| MODEL | F2IV-30 | |
| System specification | System type | Gyro stability |
| Weight | 970g | |
| Stable system | Platform type | Tri-axis |
| Azimuth | 360°rotation | |
| pitch | -100°～+100° | |
| Maximum search angular velocity | ≥100°/s | |
| Stability accuracy | 0.1mrad(1°/2HZ) | |
| Angular position accuracy | ≤0.3° | |
| Visible light camera 1 | Resolution and frame rate | SONY7520
1920×1080 @60fps |
| FOV | 63°×35°～2.3°×1.3° | |
| Visible light camera 2 | Resolution and frame rate | 1920×1080 @60fps |
| FOV | 38.4°×22.2°(8mm prime lens) | |
| Infrared camera | Resolution and frame rate | 640×480@60fps |
| SMALL FOV | 12.5°×9.4°（35mm prime lens） | |
| Tracking module | Frame rate | 60Hz |
| Tracking speed | ±48 Pixel/frame | |
| System external interface | Control | RS232、NET |
| Video output | NET、SDI | |
| Power supply | Power | 12～28V |
| Power consumption | Av≤15W，Max≤30W | |
| Environmental conditions | Operating temperature | -10℃～+50℃ |
| Storage temperature | -40℃～+60℃ |
Dimensions
How it works:
The 30X three light infrared tracking universal joint combines the functions of two EO cameras and a 35mm main lens IR, providing dual light picture in picture display. The main lens EO camera combines infrared and EO images, while the 30X EO camera supports a picture in picture display option to enhance visual clarity. This universal joint is designed to provide professional level tracking function, allowing you to easily capture exciting shots.
Frequently asked questions:
Q: Can this universal joint be installed on any drone?
A: Yes, this three axis dual light tracking universal joint is compatible with most drone models. Integrated design, quick disassembly structure, simple and convenient installation, and can be selected according to needs.
Q: How long is the continuous optical zoom range?
A: The universal joint provides a 30x continuous optical zoom range, allowing you to clearly capture distant objects.
Q: Does the universal joint support 360 ° rotation?
A: Yes, this universal joint supports 360 ° infinite rotation, ensuring that you can clearly capture the lens at each angle.
Q: How stable is the universal joint during flight?
A: The three-axis gyroscope stabilization system maintains extraordinary stability, ensuring smooth and stable visuals even under challenging flight conditions.
Q: Is this universal energy-saving automatic recognition bus?
A: Yes, the universal joint has advanced artificial intelligence human vehicle recognition function, which can easily identify and track people and vehicles.
Q: Does the universal joint consume a lot of electricity?
A: No, the small size and lightweight design of this universal joint are accompanied by low power consumption, ensuring extended flight time.
