FD5000 Ground Station 14 Channels Portable Drone Ground Control Station

$7,000.00

Availability: In Stock

FD5000 drone ground control station is typically a software application, running on a ground-based computer, that communicates with your UAV via wireless telemetry. It displays real-time data on the UAVs performance and position and can serve as a “virtual cockpit”, showing many of the same instruments that you would have if you were flying a real plane. A GCS can also be used to control a UAV in flight, uploading new mission commands and setting parameters. It is often also used to monitor the live video streams from a UAV’s cameras. portable Ground Control Station (GCS) is a flexible and universal solution for controlling unmanned vehicles and payloads. By using a unique, modular electronics compartment (MEC), application specific hardware can be quickly installed. This flexibility allows the GCS to be configured to control unmanned aircraft vehicles (UAV), ground robots, bomb disposal robots, remotely operated vehicles (ROV) and other robotic devices. The GCS can also be configured to control and monitor measurement and sensing equipment.

Compare

Description

Specification:

CPU: In tell 3/I 5/I 7 seventh generation processor (standard I 5)
Memory: maximum support 16G (standard 4G)
Storage: Maximum support 3T solid state drive (standard 128G)
Graphics: Intel HD Graphics 620
Network: 1 Gigabit Ethernet port (optional dual Ethernet ports)
System: Windows 7/10/Linux
Screen size: 13.3 inches
Resolution: 1920*1080
Brightness: 1000ccd/m²
Touch screen: 10-point capacitive touch screen on the lower screen
Battery: 16.8V12AH
Power display: computer system display / led power
Charging time: 3-4 hours
Working time: 3-4 hours
Size: 462*256*70mm
Weight: 6.9KG
Storage temperature: -20-70℃
Working temperature: -10-60℃
External interface: 2*USB 2.0/2*USB 3.0/1*LAN/1*HDMI
Remote control and other parameters
Rocker: 2*potentiometer rocker+2*return center hall rocker
Lever: 6* third gear lever
Parameter adjustment method: upper computer
Image access: HDMI or network port
Internal reserved space: 170*90*27mm
Output power supply: 12V (maximum 3A)
Antenna interface: 2*external N head
Joystick output mode: S-BUS/USB-HID
